EPDM rubber sheets are renowned for their outstanding insulation capabilities. They can effectively insulate electricity, making them safe for use in environments where electrical conductivity needs to be minimized. This property is particularly valuable in factories with electrical equipment, where the risk of electrical leakage or short circuits must be mitigated.
In addition to their insulation properties, EPDM rubber sheets exhibit remarkable resistance to acids and alkalis. They can withstand prolonged exposure to corrosive substances without degrading, which makes them ideal for use in chemical processing plants or warehouses that store acidic or alkaline materials. Their ability to maintain structural integrity in such harsh conditions ensures long-term reliability and reduces the need for frequent replacements.
Neoprene rubber sheets, especially those enhanced with EPDM compounds, deliver unmatched durability and adaptability across industrial environments. Engineered to withstand extreme conditions, our rubber sheets are the go-to choice for factory flooring, machinery sealing, pipe gaskets, equipment insulation, and shock-absorbing pads.
✅ High-Temperature Resistance – Maintains integrity at 150°C (302°F) continuously (ASTM D2000 verified)
✅ Chemical & Oil Resistance – Withstands acids, alkalis, oils, and solvents (compatible with ASTM F146 testing)
✅ Electrical Insulation – Dielectric strength up to 25 kV/mm (IEC 60243-1 certified)
✅ Abrasion & Aging Resistance – 50% longer lifespan vs. standard rubber sheets
✅ Customizable – Cut-to-size sheets or CAD-designed precision parts
| Application | Performance Highlights |
|---|---|
| Factory Flooring | Anti-slip texture, withstands heavy equipment traffic |
| Pipe Sealing | Compression set ≤15% (ASTM D395) for leak-free joints |
| Machine Padding | Vibration damping reduces noise by 30 dB (ISO 10846) |
| Thermal Insulation | Thermal conductivity ≤0.25 W/m·K (ASTM C518) |
| Chemical Tanks | Resists 98% sulfuric acid & 50% NaOH solutions |
| Property | EPDM-Enhanced Sheet | Basic Neoprene |
|---|---|---|
| Max Temp | 150°C | 120°C |
| Weathering | 10+ years outdoors | 5-7 years |
| Ozone Resistance | No cracking (ASTM D1149) | Moderate |
| Cost Efficiency | 2x lifespan = 40% TCO reduction | Lower upfront cost |
Size & Thickness – 0.5mm to 50mm thickness; sheet sizes up to 2m×10m
Precision Cutting – Waterjet/Laser cutting for complex shapes (tolerances ±0.5mm)
Surface Treatments – Embossed, adhesive-backed, or conductive coatings
Certification Support – ROHS, REACH, FDA (for food-grade applications)
Material: EPDM-Neoprene Hybrid (70A-90A Durometer)
Color: Black (standard), red/green (customizable)
Standards: ISO 9001, UL 94 HB flame rating
Lead Time: 3-7 days for stock sizes; 2 weeks for custom orders
Surface Prep – Clean with solvent (alcohol/acetone)
Adhesive – Use neoprene-compatible cement (we provide recommendations)
Curing – 24h at 20-25°C for full bond strength
✧ Free Samples – Test before bulk orders
✧ MOQ 1㎡ – Perfect for prototyping
✧ Global Shipping – DDP terms available to 150+ countries
Request a Quote Today & Get:
CAD Design Support
Material Compliance Certificates
12-Month Performance Warranty
EPDM rubber sheets are truly versatile materials with a wide range of applications in industrial settings. Their excellent insulation properties, resistance to acids, alkalis, and oils, as well as their wear resistance and elasticity, make them ideal for use in factories, warehouses, and machinery. With the ability to withstand high temperatures and be customized to fit any application, EPDM rubber sheets offer a reliable and durable solution for various industrial needs. Whether used for flooring, sealing, insulation, or cushioning, EPDM rubber sheets are a valuable asset in ensuring the efficiency and safety of industrial operations.
Request free samples & technical drawings today!
